Description
The Castelgarden XDC150e lawn tractor provides the perfect blend of power and pleasure. This rugged riding lawn mower is driven by a strong STIGA 30Ah (Li-Ion) battery pack, developed and tested by STIGA in Italy. The result? Lawn coverage up to 3000sqm and a running time up to 45 minutes on just one charge – without engine noise, fumes and hassle of a petrol riding lawn mower. It also comes with a spacious 240l grass collector, plus a mulching plug and blades if you’d prefer to spread fine cuttings over your lawn.
The Castelgarden XDC150e’s battery combines the comfort of a sit-on lawn motor with the power of a petrol lawn tractor. And because the battery’s so powerful and durable, you’ll enjoy rides lasting up to 45 minutes, covering up to 3000sqm on one charge.
Your sit-on mower comes with a 240l grass collector, so you can focus on cutting your lawn, not going to the garden bin. An intuitive dashboard features the battery power status and quick-press start button.
A powerful 1.2kW transaxle motor lets you reach speeds of up to 9km/h, while two cutting blade motors totalling 3kW are free from belts, pulleys and expensive maintenance. And thanks to an ample 84cm cutting width, adjustable to 7 heights between 25 to 80mm, you’ll be finished and parked quickly.
CUTTING SYSTEM
| Minimum uncut radius | 80 cm |
|---|---|
| Cutting method | Collecting |
| Cutting width | 84 cm |
| Reverse mowing | Yes |
| Blade rotation | Untimed |
| Cutting height adjustment | Manual with lever |
| Cutting height positions | 7 positions |
| Cutting height range | 25 – 80 mm |
| Number of blades | 2 |
| Blade type | Winged |
| Additional cutting method | Rear discharge, Mulching |
| Blade engagement type | Electric |
POWER
| Charging time | 6 h |
|---|---|
| Battery capacity | 30 Ah |
| Power source | Lithium-ion battery |
| Power | 3 kW |
| Battery kit | Included |
| Voltage | 48 V |
| Battery type | Lithium-ions |
| Lithium battery nominal energy | 1500 Wh |
| Number of cells | 168 |
| Charging current | 5 A |
| Charging system | External charger |
| Temperature control | Yes – temperature sensors |
| Maximum working area | 3000 |
TRANSMISSION
| Transmission type | Electric |
|---|---|
| Transmission method | Pedal-operated |
EQUIPMENT
| Collector emptying | Manual |
|---|---|
| Collector capacity | 240 l |
| Steering wheel | Castelgarden ergonomic |
| Seat type | Castelgarden classic |
| Seat adjustment | Screws |
| Dashboard | Yes with LED |
| Front wheel size | 15×6.00-6 |
| Rear wheel size | 18×8.50-8 |
| Headlights | Led |
| Bumper | Yes |
| Washing link | Yes |
| Collector type | Textile |
| Storage compartment | Yes |
| Cup holder | Yes |
| Pivoting front axle | Yes |
| Antiscalp wheels | 2 |
| Safety system | Seat with Safety Contact Breaker |
TOOLS KIT
| Mulching kit | Optional |
|---|---|
| Battery charger | Single standard |
| Trailer hitch kit | Not applicable |
OVERALL DIMENSIONS
| Pack weight | 233 kg |
|---|---|
| Product length | 2340 mm |
| Product width | 902 mm |
| Product height | 1098 mm |
DRIVE SYSTEM
| Traction | Rear-wheel drive |
|---|
