Description
Features
- For 216mm(8-1/2″) Blade
- Slide guided rigidly by dual linear ballbearings for accurate cutting
- Max cut capacity height 65mm x width312mm at 0ºcross cut
- Power input 1,050W and no-load speed 5,500/min.
- Lightweight 14kg in comparison with 216mm(8-1/2″) slide compound miter saws
- Soft grip handle
- Pivoting Sub-Fence as an optional
- Head swivel system adjusts 48º left for bevel, and compound cuts of both 45ºbevel to left, and 45º miter to left/right
- Positive miter stops: 0º, 15º, 22.5º, 31.6º, and 45º (right/left)
- Rigid die cast base with turn table
- Equipped with chip de ector
Specifications
| Capacity | Blade Dia. | 216mm (8-1/2″) |
| (H x W) Cross Cut 0º | 65 x 312mm (2-9/16 x 12-1/4″) 75 x 262 mm (2-15/16 x 10-5/6”) by aux. board |
|
| (H x W) Miter Cut 45º | 65 x 220mm (2-9/16 x 8-21/32″) 75 x 185 mm (2-15/16 x 7-1/4”) by aux. board |
|
| (H x W) Bevel Cut 45º | 45 x 312mm (1-25/32 x 12-1/4″ ) | |
| Compound Mter 45º and Beve 45º | 45 x 220mm (1-25/32 x 8-21/32″) | |
| Power Input | 1,050W | |
| No Load Speed | 5,500/min. | |
| Miter Angle | Right | 0 – 57º |
| left | 0 – 45º | |
| Bevel Angle | Right | 0 – 5º |
| left | 0 – 48º | |
| Positive Angle Stop | 0, 15, 22.5, 31.6 and 45º | |
| Dimensions | 555 x 790 x 485mm(21-27/32 x 31-3/32 x 19-3/32″) | |
| Weight | 14kg (31.0lbs.) | |
| Standard Accessories | Blade, Dust Bag, Vise Assy, Wrench | |
